DS18 EQX7PRO- High Volt 7-Band Equalizer with High Level Input, Auto Turn On And High Volt LED Indicator

DS18 EQX7PRO- High Volt 7-Band Equalizer with High Level Input, Auto Turn On And High Volt LED Indicator

$119.95 USD
$119.95 USD
Sale Sold out
Shipping calculated at checkout.

  • KEY FEATURES

    • 1/2 DIN 7 Band Graphic Equalizer
    • MAX Output: 8 Volts
    • 7 Volt-Output LED Indicator
    • Subwoofer Level Control
    • High Level & AUX Inputs
    • Master Volume Control
    • The EQX7PRO allows you to take complete control of your audio system, pushing it past its limits with unparalleled precision and clarity. This high-strength 7-band stereo equalizer/crossover is the upgrade needed to achieve your audio dreams.

    SPECS

    SKU
    EQX7PRO
    Type of Equalizer
    Graphic
    Number of bands
    7
    Frequency Point HZ
    50, 125, 320, 750, 2.2k, 6k, 16k
    Boost/Cut
    12dB (15dB Subwoofer Frequency)

    CROSSOVER SECTION

    Passive Crossover Ways / Type
    1 (LPF) (Subwoofer Ch)
    Frequency Crossover point
    60/120Hz Selectable
    Cut-Off Slope
    12dB/Oct

    AUDIO SPECIFICATIONS

    S/N Ratio
    100dB
    THD
    0.005%
    Input Sensitivity
    50mV-3V
    Input Impedance
    20Kohm
    Output Voltage
    8V
    Output Impedance
    2Kohm
    Head Room
    20dB
    Stereo Separation
    82dB @ 1Khz
    Frequency Response
    10Hz-30Khz

    GENERAL FEATURES

    Operating Voltage
    11-15V
    Subwoofer Output
    Yes (9V)
    Audio Controls
    Subwoofer Level, Master Volume, Fader
    Audio Inputs
    Main (RCA), Auxiliar (RCA)
    RCA Type
    Gold-plated
    Housing Material
    Metal / Aluminum
    Adjustments
    Aux Input Gain
    Extra Features
    Blue Backlit with Red 7V output indicator
    Hi-Level Speaker Input
    Yes
    Auto Turn-on
    Yes (Hi-Level input)
    Remote Turn-on Input/Output
    Yes Input and Output
    Color / Finish
    Satin Black

    MEASUREMENTS

    Overall Length
    7" / 178mm
    Overall Depth
    4.4" / 112mm
    Overall Height
    1.18" / 30mm
    Gross Single Unit Weight (lb)
    1.85
    Single Unit Box Dimensions W x L x H (Inches)
    9 x 6.25 x 1.75
