Cs Pro Audio LLC, DS18

DS18 SXE-1200.4- SXE Class A/B 4-Channel Full-Range Car Amplifier 4 x 60 RMS @4 Ohm 1200 Watts

DS18 SXE-1200.4- SXE Class A/B 4-Channel Full-Range Car Amplifier 4 x 60 RMS @4 Ohm 1200 Watts

$155.95 USD
$155.95 USD
Sale Sold out
Shipping calculated at checkout.

  • KEY FEATURES

    • Full Range Amplifier
    • 4 Channel
    • Class A/B
    • 2 ~ 4 Ohm Stable
    • 4 x 60 Watts @ 4 Ohm
    • Compact Design

    SPECS

    SKU
    SXE-1200.4
    Total Watts (Peak)
    1200W
    RMS Power @ 4 Ohm
    4 x 60W
    RMS Power @ 2 Ohm
    4 x 100W
    RMS Power @ 4 Ohm Bridge
    2 x 200W

    AUDIO

    Frequency Response
    10Hz-20KHz
    Signal to Noise Ratio
    90dB
    Efficiency @ 4 Ohm
    64%
    Damping Factor
    170
    Input Impedance
    20kΩ
    Channel Separation
    45dB
    Total Harmonic Distortion (THD)
    0.05%
    Low Level Input Range
    200mV-5V
    Selectable X-Over
    HPF/FULL/LPF
    X-Over Filter Range
    40HZ-2KHZ

    FEATURES

    Amplifier Class
    Analog (AB)
    Amplifier Type
    Stereo Full Range
    Number of Channels
    4
    Minimum Impedance
    2 Ohm Stereo / 4 Ohm Bridge
    Led Indicator
    Power/Protect/Clip
    Power Input Terminal Size
    4Ga
    Fuse Size
    2 x 25A (50A)
    Cooling Fan
    Yes
    Thermal Protection
    Yes (80°C)
    Over-Load Protection
    Yes
    DC Output Protection
    Yes
    Short Circuit Output Protection
    Yes
    Voltage Input Protection
    Yes (16.5v)
    Clipping Protection
    Yes
    Body Color
    Red / Black Brushed Aluminum

    MEASUREMENTS

    Overall Length
    9.81” / 249.3mm
    Overall Wide
    5.51” / 140mm
    Overall Height
    1.88” / 48mm
    Heatsink Length
    8.34” / 212mm
    Gross Single Unit Weight
    1.76KG
